Purpose and scope of applicationя
The AFG is designed to compensate for harmonic components of the current consumed by a nonlinear load in a three-phase power supply network and is intended for outdoor operation under conditions specified for the UHL1 climatic version according to GOST 15150-69.
Functional capabilities
AFG provides the following functions:
- Automatic compensation of harmonic components of current up to the 40th harmonic.
- Manual or automatic compensation control mode.
- Recording and storing data on the operation of the AGF, including measurements, events and parameter changes.
- Automatic switching on after power failure with adjustable delay.
- Setting protection settings and compensation parameters via the controller menu.
